1. The 10Gtek RT-M40113- COO is a Four-Channel, Pluggable, Parallel, Fiber-Optic QSFP+ Transceiver for InfiniBand QDR/DDR/SDR,10G/8G/4G/2G fiber channel, PCle and SAS Applications.
2. The QSFP full-duplex optical module offers 4 independent transmit and receive channels, each capable of 10.7Gbps operation for an aggregate data rate of 42.8Gbps 1.4km using single mode fiber.
3. These modules are designed to operate over single mode fiber systems using 1310nm FP laser array.
4. An optical fiber ribbon cable with an MPO/MTP™ connector can be plugged into the QSFP module receptacle. QSFP+ PSM IR4 is one kind of parallel transceiver which provides increased port density and total system cost savings.
Application
1. 40G Ethernet
2. Data Center
3. Back to Back
4. InfiniBand QDR, DDR and SDR
Features
1. 4 independent full-duplex channels
2. Up to 11.2Gb/s data rate per channel
3. High Reliability 850nm VCSEL technology
4. MTP/MPO optical connector
5. QSFP+ MSA compliant
6. Electrically hot-pluggable
7. Up to 100m transmission on OM3 multi- mode fiber or 150m links on OM4 multimode fiber
8. RoHS compliant and lead-free
9. Digital diagnostic capabilities
10. Single +3.3V power supply
11. Maximum power consumption 1.5W
12. All-metal housing for superior EMI performance
13. Case operating temperature: -40 ~ +85°C
