1.Optical fiber communication systems engineering.
2.Fiber optic data communication network.
3.Fiber CATV engineering.
4.Other optical technology tests.
Features
1.The style is diverse, the interface is complete.
2.Low insertion loss and added loss.
3.Height of attenuation.
4.High back loss, small volume, light weight.
5.End-face geometry and quality superior than IEC and Telcordia standards.
6.LSZH, OFNP, OFNR cable jacket.
7.Mechanical performance: IEC 61754-20 standard.
8.RoHS and REACH materials compliant.
Specification
Characteristic | SM , MM | ||||
Connector type | ST | ||||
Diameter(mm) | |||||
Polishing grade | SM PC | MM PC | UPC | APC | |
Insertion loss | ≤0.3dB | ≤0.4dB | ≤0.2dB | ≤0.3dB | |
Return loss | ≥40dB | ≥50dB | ≥65dB | ||
Interchangeability | ≤0.2dB | ||||
Repeatability | ≤0.2dB | ||||
Operation temperature （℃） | -40~+85 | ||||
