1. Local area network.
2. Optical fiber communication system.
3. Optical Fiber CATV
4. Optical fiber sensor.
5. Fiber optics data transmission(FODF)
6. Active device termination.
7. Equipment test.
Features
1. Accurate mechanical dimensions.
2. Low insertion loss, high return loss.
3. Excellent compatibility.
4. Excellent repeatability.
5. Excellent temperature stability.
6. No polishing, no epoxy.
7. More convenient to install,
8. Life time: our fiber optical fast connector have at least 1 years lifetime, because we introduce advanced production technology and 100% new raw material and well quality control.
Specification
Parameter | Unit | LC, SC, FC, ST, MTRJ, MPO | |||
SM | MM | ||||
PC | UPC | APC | PC | ||
Insertion loss | dB | ≤0.2 | ≤0.2 | ≤0.2 | ≤0.2 |
Return loss | dB | ≥45 | ≥50 | ≥60 | ≥30 |
Exchangeability | dB | ≤0.2 | |||
Repeatability | dB | ≤0.2 | |||
Durability | Time | >1000 | |||
Operating temperature | ℃ | -40 – 75 | |||
Storage temperature | ℃ | -40 - 85 | |||
